Konstruktion : Gehäuse aus Aluminumprfil, Endkappen aus ABS Kunststoff.
Einsatzbereiche : Bügelbefestigung an Wand und Decke
Leuchtenabdeckung / Diffusor : Transparenter Schutz Diffusor aus schlagfesten PC.
| Lichtausbeute der verwendeten LED’s, lm/W | 110-120 |
| Spannungsversorgung, V | 220 50Hz |
| Leistungsaufnahme im Nennbetrieb, W | 43 |
| Netzkabel-Schnitt, max., mm2 | 1,5 |
| Gehaeuse | Eloxal |
| Lichttemperatur, K | 5500 |
| Arbeitstemperaturen, C° | von- 40bis +40 |
| Lichtstrom, lm | 3960 |
| Leistungsfaktor cos(phi), mind. | 0,99 |
| Auxenmaxe, mm | 276x180x157 |
| Strahlwinkel | 120° |
| Farbwiedergabe-Index Ra, mind. | 80 |
| Ressource des Leucht-Diode-Chip (beim Betrieb 12 Stunden pro Tag), Jahre mind. | 20 |
| Garantie-Nutzungsdauer, Jahre | 3 |
| Anzahl LED, St. und deren Brand | 36,Cree |
| Feuchteschutz (ingress protection) | Ip65 |
| Power W | 32 | Weight Kg | 3.5 |
| Anschluß V | 220 +/-10% 50Hz | Luminous Efficacy l/W | 170-185 |
| Illuminance lm | 3160 | No:of LED | 60 |
| Color Temperature | 4500 | Width mm | 185 |
| Length mm | 850 | Height mm | 40 |
| Beam angle | 120 | Maximum section of mains cable, mm2 | 1.5 |
| Protection class | ip40 | Color | White |
